225 Wpc ( 8 ohm) Integrated amplifier with line, balanced and phono input.

‍PHONO PREAMPLIFIER
The phono preamplifier is suitable for moving magnet and high-output moving coil cartrdiges

Input Impedance 47 kΩ

‍Input Capacitance 100 pF

‍Maximum Input 18 mV at 20 Hz, 140 mV at 1 kHz, 160mV at 20 kHz‍

Gain (at 1 kHz) 35 dB

‍Crosstalk (at 1 kHz) 80 dB

‍RIAA Response+/- 0.5 dB (100 Hz to 20 kHz); -1 dB (20 Hz)

‍THD+N (at 1 kHz, 5 mV input) 0.05%

‍S/N Ratio (ref. 5 mV at 1 kHz, IEC-A filter) 83 dB

‍PREAMPLIFIER

Input Impedance 30 kΩ'

Pre-Out' Output Impedance 560 Ω

‍'Rec-Out' Output Impedance 100 Ω

‍Rated Input 1.0 Vrms

‍Maximum Input 7.6 Vrms

‍Minimum Load 5 kΩ

‍Rated Output (100 k1 load) 1.0 Vrms

‍Maximum Output (100 k1 load) 7.6 Vrms

‍Headphone Output 500 mW into 32 Ω at 0.03% THD+N

‍Channel Separation (at 1 kHz) 75 dB

‍Crosstalk Between Inputs (at 1 kHz) 72 dB

‍XLR Pin ConfigurationPin 1: Ground; Pin 2: Positive; Pin 3: Negative

‍Frequency Response and Bandwidth 20 Hz to 20 kHz (+0, -0.1 dB); 1 Hz to 170 kHz (+0, -3 dB)

‍THD+N (at rated input and output, 80 kHz BW) 0.003%

‍IMD (CCIF at 15 kHz and 16 kHz) 0.0005%

‍S/N Ratio (A-weighted, ref 2.0 Vrms) 105 dB

‍POWER AMPLIFIER

225Wpc into 8Ω  (310Wpc into 4Ω)
(per channel, continuous RMS, 20 Hz to 20 kHz, <1.0% THD)

Frequency Response 20 Hz to 20 kHz (+0, -0.15 dB)

‍Bandwidth1 Hz to 200 kHz (+0, -3 dB)

‍THD+N 0.01% at 1 kHz, 0.03% at 20 kHz (100 W into 8 1)

‍Power Bandwidth < 10 Hz to 100 kHz (+0, -3 dB, 200 W into 8 1)

‍Slew Rate 25 V/µs

‍Headroom 1.4 dB (8 1), 2.8 dB (4 1)

‍Damping Factor 80 at 1 kHz (ref. 8 1)

‍S/N Ratio (A-weighted, ref 225 W) 105 dB

‍Crosstalk> 57 dB (100 Hz to 10 kHz)

‍Voltage Gain 29 dB

‍TriggerInput PolarityNon-polarizedOutputPass-through of input

‍

‍

‍

Power cord and remote control included.

Serial No. 114830828
